Description
- ADA compliance: When installed at recommended mounting height, unit complies with ADA requirements for accessibility by handicapped persons (maximum height and reach, minimum knee clearance and distance from obstructions).
- Spray Head Assembly: Four vandal resistant GS-Plus™ spray heads. Each head has a brass body, stainless steel “flip top” dust cover, internal flow control and filter to remove impurities from the water flow. Spray heads have retaining ring with set screw to protect internal components.
- Valve: 1/2” IPS brass stay-open ball valve. Valve is US-made with chrome plated brass ball and Teflon® seals.
- Bowl: 11 1/2” stainless steel with wraparound skirt and bottom panel with one-way screws.
- Mounting: Bowl and skirt unit has welded stainless steel bracket for wall mounting.
- Supply: 1/2” NPT female inlet.
- Waste: 1 1/2” OD chrome plated brass tailpiece.
- Sign: ANSI-compliant identification sign. quality assurance: Unit is completely assembled and water tested prior to shipment.
Manufacturer Info
Guardian Equipment is the innovative leader in the emergency eyewash and shower industry. Guardian is continually expanding their product offering to remain the best resource for emergency response needs.
