Description
APPLICATION
Designed for installation on potable water lines to protect against backsiphonage of contaminated water into the potable water supply. Assembly shall provide protection where a potential health hazard exists.
STANDARDS COMPLIANCE
- ASSE ® Listed 1020
- IAPMO® Listed
- CSA ® Certified
- Approved by the Foundation for Cross-Connection
- Control and Hydraulic Research at the University of Southern California
MATERIALS
- Main valve body: Cast Bronze ASTM B584
- Fasteners: Stainless Steel, 300 Series
- Elastomers:
- Silicone (FDA approved)
- Buna Nitrile (FDA approved)
- Polymers:
- Polypropylene (FDA approved)
- Delrin® (FDA approved)
- Springs: Stainless Steel, 300 series
FEATURES
- Maximum working water pressure 150 PSI
- Maximum working water temperature 110°F
- Hydrostatic test pressure 300 PSI
- End connections threaded ANSI B1.20.1
