Sloan Royal 186-0.125-ES-S Sensor Flushometer

Sloan Royal 186-0.125-ES-S Sensor Flushometer

Item #: 169242
|
Model: ROYAL 186-0.125-ES-S
|
Manufacturer: Sloan

If you are looking to find Sloan products quickly and easily, you’ve come to the right place. This Sloan Royal 186-0.125-ES-S Sensor Flushometer is a direct replacement product manufactured by Sloan. Order this Sloan ROYAL 186-0.125-ES-S today and you will have your Sloan project completed in no time at all.

0.125 GPF (gallons per flush)
For Urinals
3/4” Spud Size
9” Vacuum Breaker

This Item Typically Ships in 1-2 Weeks

Find Parts

$537.58

Product Description
Specifications
Reviews (0)
Questions (0)

Product Description

Description

Specifications

Quiet, Exposed, Diaphragm Type, Chrome Plated Urinal Flushometer for either left or right-hand supply with the following features:

High Chloramine Resistant PERMEX® Synthetic Rubber Diaphragm with Linear Filtered Bypass and Vortex Cleansing Action™
Vacuum Breaker with Flush Connection
Sweat Solder Adapter with Cover Tube and Cast Wall Flange
Low Consumption flush accuracy
¾” I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
Spud Coupling and Spud Flange for ¾” Top Spud
No External Volume Adjustment to Ensure Water Conservation
OPTIMA® EL-1500 Self-Adaptive Infrared Sensor with Indicator Light

Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Red Brass. Valve shall be in compliance to the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.

Diaphragm, Stop Seat and Vacuum Breaker to be molded from PERMEX® rubber compound for Chloramine resistance

Control Circut

Solid State
8 Second Arming Delay
24 VAC Input
24 VAC Output

Solenoid Operator

24 VAC, 50/60 Hz

Sensor Range

Nominal 12” – 32” (305 mm – 813 mm) Self-adaptive Window: ± 10” (254 mm)

Automatic Operation

Sloan OPTIMA® equipped Flushometers provide the ultimate in sanitary protection and automatic operation. There are no handles to trip or buttons to push. The Flushometer operates by means of an infrared sensor that adapts to its surrounding. Once the user enters the sensor’s effective range and then steps away, the Flushometer Solenoid initiates the flushing cycle to flush the fixture.

Hygenic

User makes no physical contact with the Flushometer surface except to initiate the Override Button when required. Helps control the spread of infectious diseases.

Economical

Automatic operation provides water usage savings over other flushing devices. Reduces maintenance and operation costs.

Practical

Solid state electronic circuitry assures years of dependable, trouble-free operation. The operational components of the Flushometer are identical to a handle activated Sloan® Flushometer, proven by over 100 years of experience.
