Sloan ECOS G2 8186-1.0 Sensor Flushometer

Sloan ECOS G2 8186-1.0 Sensor Flushometer

Item #: 169780
|
Model: ECOS G2 8186-1.0
|
Manufacturer: Sloan

If you are looking to find Sloan products quickly and easily, you’ve come to the right place. This Sloan ECOS G2 8186-1.0 Sensor Flushometer is a direct replacement product manufactured by Sloan. Order this Sloan ECOS G2 8186-1.0 today and you will have your Sloan project completed in no time at all.

1.0 GPF (gallons per flush)
For Urinals
3/4” Spud Size
9” Vacuum Breaker

This Item Typically Ships in 1-2 Weeks

Find Parts

List Price: $955.85 $621.30 You Save 35%

Qty:

Product Description
Specifications
Documents
Reviews (0)
Questions (0)

Product Description

Description

Automatic Operation

Sloan ECOS® Flushometers can also be activated via multi-lobular infrared sensor. By detecting user presence and duration, the Sloan ECOS® Smart Sense Technology™ will determine the proper flush volume for unequaled water efficiency.

Specifications

Quiet, Exposed, Chrome Plated Urinal flushometer for either left or right hand supply with the following features:

Synthetic rubber seals for chloramine resistance
Initial Set-up Range Indicator Light (first 10 minutes)
“Low Battery” Flashing LED
Sweat solder adapter with cover tube and cast wall flange with set screw
Spud coupling and flange for 3/4” top spud
Stop Seat and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine resistance
Infrared Sensor with Multiple-focused, Lobular Sensing Fields for high and low target detection
Latching Solenoid Operator
Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation
Engineered Metal Cover with replaceable Lens Window
Four (4) Size AA Alkaline Batteries included: Duracell® with DURALOCK Power Preserve TechnologyTM-guaranteed for up to 10 years in storage
Courtesy Flush® Override Button (optional)
Reduces water usage up to 80% over standard sensor urinal
ADA Compliant Sloan ECOS® Battery Powered Infrared Sensor for automatic “No Hands” operation
3/4” IPS screwdriver Bak-Chek® angle stop with vandal resistant stop cap
Valve Body, Cover, Tailpiece and Control Stop shall be in conformance with ASTM Alloy Classification for Semi-Red Brass. Valve shall be in compliance with the applicable sections of ASSE 1037 and ANSI/ASME 112.19.2.
Sentinel Flush, Automatic flush once every 24 hours after the last flush. Product shipped from factory with feature turned off. Consult factory to activate

Manufacturer Info

Sloan is the premier manufacturer of restroom products and systems for the commercial market. Sloan Flushometers, Sloan Faucets and other engineered systems provide owners with the ultimate in tenant and employee convenience – while saving water.

Specifications Documents Reviews (0) Questions (0)

Frequently bought together

Customers who bought this product also commonly purchased the following combination of items.

This Item: Sloan ECOS G2 8186-1.0 Sensor Flushometer
Sloan G2 8110 Sensor Flushometer
List Price: $965.45 $627.54 You Save 35%
Sloan V-500-AA Vacuum Breaker 3/4" x 9"
List Price: $44.20 $37.13 You Save 16%
Sloan G2 RESS-C 1.6 or 3.5 GPF Retrofit Kit (for toilets)
List Price: $731.25 $475.31 You Save 35%
Total Price $1,761.28

Total Price Excl. Tax: $1,761.28 Incl. Tax: $1,761.28

Customers Who Bought This Item Also Bought

Sloan G2 8110 Sensor Flushometer
List Price: $965.45 $627.54 You Save 35%
Sloan V-500-AA Vacuum Breaker 3/4" x 9"
List Price: $44.20 $37.13 You Save 16%
Sloan G2 RESS-C 1.6 or 3.5 GPF Retrofit Kit (for toilets)
List Price: $731.25 $475.31 You Save 35%
Sloan EBV-136-A G2 Solenoid
List Price: $50.20 $39.16 You Save 22%
Sloan F-5-A Flushometer Spud Coupling Assembly for 3/4" Urinal Vacuum Breaker
List Price: $27.30 $22.93 You Save 16%
Sloan EHD-501 Sensor Hand Dryer
List Price: $1,593.30 $1,035.65 You Save 35%

Sloan ECOS G2 8186-1.0 Sensor Flushometer

Description

Automatic Operation

Specifications

Manufacturer Info

Documents

Write Your Own Review

You're reviewing: Sloan ECOS G2 8186-1.0 Sensor Flushometer

How do you rate this product? *

Ask Your Question

Sloan G2 8110 Sensor Flushometer

Sloan V-500-AA Vacuum Breaker 3/4" x 9"

Sloan G2 RESS-C 1.6 or 3.5 GPF Retrofit Kit (for toilets)

Sloan EBV-136-A G2 Solenoid

Sloan F-5-A Flushometer Spud Coupling Assembly for 3/4" Urinal Vacuum Breaker

Sloan EHD-501 Sensor Hand Dryer

Kully Item #	169780
Manufacturer	Sloan
Model #	ECOS G2 8186-1.0
Manufacturer Part #	3370435
UPC Code	671254378223
Toilet/Urinal	Urinal
Gallons Per Flush (GPF)	1.0 GPF
Vacuum Breaker Length	9"
Spud Size	3/4"
