Guardian G1909P Combination Drench Shower & Eye/Face Wash (with Plastic Receptor)

Description

NOTE: This unit is shown with a stainless steel receptor. The G1909P has an orange ABS plastic receptor.

• Showerhead: 10” diameter orange ABS plastic.
• Shower Valve: 1” IPS chrome-plated brass stay-open ball valve. Valve is US-made with chrome-plated brass ball and Teflon seals. Furnished with stainless steel actuating arm and 29” stainless steel pull rod.
• Sprayhead Assembly: Four GS-Plus sprayheads. Each head has a “flip top” dust cover, internal flow control, and filter to remove impurities from the water flow.
• Eye/face Wash Receptor: 11-1/2” diameter. Receptor is stainless steel (G1909) or orange ABS plastic (G1909P).
• Eye/face Wash Valve: 1/2” IPS chrome-plated brass stay-open ball valve. Valve is US-made with chrome-plated brass ball and Teflon seals.
• Pipe and Fittings: Schedule 40 galvanized steel. Furnished with orange polyethylene covers for vertical piping for high visibility and corrosion resistance.
• Supply: 1-1/4” NPT female top or side inlet.
• Waste: 1-1/4” NPT female outlet. Outlet can be positioned at either 8” or 20” above finished floor by reversing lower pipe nipples.
• Sign: Furnished with ANSI-compliant identification sign.
