Description
Chicago Faucets No. 730-244COLDABCP polished chrome plated solid brass construction. 3 3/8” center to center integral cast brass spout. 2.2 GPM (8.3 L/min) pressure compensating Softflo aerator. 2 3/8” metal lever handle(s) with eight point tapered broach and secured blue button. Klo-self™ rebuildable self-closing cartridge, immediate shut-off, opens and closes 90° bi-directional, features square tapered stem. Integral inlet shank(s) contains standard 1/2” NPSM supply inlet with coupling nut for 3/8” or 1/2” flexible riser. 3 3/8” center to center integral cast brass spout. Mounting hardware included. This product meets ADA ANSI/ICC A117.1 requirements and is tested and certified to industry standards: ASME A112.18.1M, and CSA B125.1.
Product Type
Deck Mounted Single Supply Cold Water Sink Faucet
Features & Specifications
• Single Hole
• 2.2 GPM (8.3 L/min) Aerator
• 2 3/8” Lever Handle
• Klo-Self Metering Cam and Cap Design Operating
Cartridge
• 1/2” NPSM Supply Inlet with Coupling Nut for 3/8” or 1/2”
Flexible Riser
• 3 3/8” Center to Center Integral Cast Brass Spout
Performance Specifications
• Rating Operating Pressure: 20-125 PSI
• Rated Operating Temperature: 40-140ºF
Warranty
• Lifetime Limited Faucet Warranty
• 5-Year Limited Cartridge Warranty
• 1-Year Limited Finish Warranty
Codes & Standards
• ASME A112.18.1M
• CSA B125.1
• ADA ANSI/ICC A117.1
Manufacturer Info
The Chicago Faucet Company has offered commercial and residential products built to stand the test of time. A combination of the best engineering, finest materials and quality workmanship has made Chicago Faucets the specified choice in many of the finest building products.
