Description
Chicago Faucets No. 510-GCTFWSLABCP tin plated inside, polished chrome plated outside solid brass construction. spray. 2 3/8” metal lever handle(s) with eight point tapered broach and secured blue and red buttons. Quaturn™ rebuildable compression cartridge, opens and closes 90°, closes with water pressure, features square tapered stem. 23” riser with spring guide. 44” flexible stainless steel hose with insulated handle. Mounting hardware included. This product is tested and certified to industry standards: ASME A112.18.1M, and CSA B125.1.
Product Type
Wall Mounted Wall Mounted Pre-Rinse Fitting
Features & Specifications
• 8” Body, Adjustable Arms 7 1/4” – 8 3/4”
• Spray
• 2 3/8” Lever Handle
• Quaturn Compression Operating Cartridge
• Offset 3/8” Offset Inlet Supply Arm with Integral Check
• 3” Threaded Inlet and Shank Assembly
• 23” Riser with Spring Guide
• 44” Flexible Stainless Steel Hose with Insulated Handle
Performance Specification
• Rating Operating Pressure: 20-125 PSI
• Rated Operating Temperature: 40-140ºF
Warranty
Lifetime Limited Faucet Warranty
• 5-Year Limited Cartridge Warranty
• 1-Year Limited Finish Warranty
Codes & Standards
• ASME A112.18.1M
• CSA B125.1
Manufacturer Info
The Chicago Faucet Company has offered commercial and residential products built to stand the test of time. A combination of the best engineering, finest materials and quality workmanship has made Chicago Faucets the specified choice in many of the finest building products.
