Description
Chicago Faucets No. 510-GCLABCP polished chrome plated solid brass construction. deck mounted pre-rinse fitting. spray. 2 3/8” metal lever handle(s) with eight point tapered broach and secured blue and red buttons. Quaturn™ rebuildable compression cartridge, opens and closes 90°, closes with water pressure, features square tapered stem. 23” riser with spring guide. 44” flexible stainless steel hose with insulated handle. Mounting hardware included. This product meets ADA ANSI/ICC A117.1 requirements and is tested and certified to industry standards: ASME A112.18.1M, CSA B125.1, and Certified to NSF/ANSI 61, Section 9 by CSA
Product Type
Wall Mounted Wall Mounted Pre-Rinse Fitting
Features & Specifications
• 8” Body, Adjustable Arms 7 1/4” – 8 3/4”
• Deck Mounted Pre-Rinse Fitting
• Spray
• 2 3/8” Lever Handle
• Quaturn Compression Operating Cartridge
• Offset 3/8” Offset Inlet Supply Arm with Integral Check
• 23” Riser with Spring Guide
• 44” Flexible Stainless Steel Hose with Insulated Handle
• CFNow! Item Ships in 5 Days
Performance Specification
• Rating Operating Pressure: 20-125 PSI
• Rated Operating Temperature: 40-140ºF
Warranty
• Lifetime Limited Faucet Warranty
• 5-Year Limited Cartridge Warranty
• 1-Year Limited Finish Warranty
Codes & Standards
• ASME A112.18.1M
• CSA B125.1
• Certified to NSF/ANSI 61, Section 9 by CSA
• ADA ANSI/ICC A117.1
The Chicago 510-GCLCP Wall-Mounted Pre-Rinse (with Drench Hose) includes:
- Water conserving spray valve
- Lever handles
- Quaturn operating cartridge
- Adjustable supply arms with integral checks
- 44” Flexible stainless steel hose with an insulated handle
- 1/2” NPT Female inlets
Manufacturer Info
The Chicago Faucet Company has offered commercial and residential products built to stand the test of time. A combination of the best engineering, finest materials and quality workmanship has made Chicago Faucets the specified choice in many of the finest building products.
