Description
The Speakman SE-7001 Freeze-Protected Floor-Mounted Combination Drench Shower & Eye/Face Wash is wrapped with heat trace cable and insulation and jacketed with an easy access ABS shell to protect it to -50 degrees F. The eye/face wash features dual aerated spray outlets with automatic flow controls and flip top dust covers. The impeller action shower is activated by a high visibility yellow pull rod. An integral freeze valve protects the unit from freezing in case of a power outage.
Features:
- Showerhead: 8” Dia. Cycolac Yellow Plastic.
- Flow Control: Internal 20 GPM Regulator
- Freeze Valve: Activates Automatically Below 40 Degrees F.
- Valve: 1” NPTF Chrome-Plated Brass Stay-Open Ball Valve.
- Activator: Powder-Coated High Visibility Yellow Aluminum Triangular Pull Rod.
- Internal Stanchion: 1” IPS Galvanized Steel Pipe.
- Inlet: 1” NPT Male, Top Supply.
- Performance: 20 GPM @ 30 PSI
- Finish: Dura-Jade Green ABS Plastic.
Eye/Face Wash
- Sprayhead: (2) Yellow ABS Plastic Spray Outlets with Automatic Flow Control and Flip Top Dust Covers.
- Valves: ½” NPT Brass, 3-Way Chrome-Plated Ball Valve.
- Performance: 3.82 GPM @ 30 PSI
- Activator: Stainless Steel Push Handle.
Electric
- Heating Tape: Self-Limiting Parallel Resistance Cable with Braided Metal Shield.
- Thermostat: Preset, Hermetically Sealed Single Pole Contact Switch. Temperature Range 60 to 70 degrees F.
- Insulation: Closed Cell Rubber Foam.
- Junction Box: NEMA 4 Water Tight and Dust Tight, Suitable for Indoor or Outdoor Locations.
- Power Supply: 120 VAC, 60 Cycle, Single Phase.
- Electrical Classification: Class 1 Division 2 GRP. B, C, D.
- Ground Fault Protection: Installation will require minimum 30 mA GFPD.
