Description
Features
- 19 gpm @ 30 psi.
- Provides 8 gpm @ 30 psi cold water bypass in case of hot water or thermostatic element failure
- Inlet connections: ¾ in. NPT
- Outlet connection: 1 in. NPT
- Temperature range: 65°-90° F
- Maximum pressure 125 PSI
- Inlet temperature hot: 120°-140° F
- Inlet temperature cold: 33°-80° F
- Minimum temperature Differential (from valve set point): 20° F
- Automatic spring check stops
- Valve holds to a +/- 3° F temperature
- Valves provide a positive shutoff when cold water is lost
- Integral strainer check stops on inlets
- Set Point = 85°F
- Adjustable set point
- Lead-Free
- Rough Brass Finish (Standard)
Compliance
- ASSE 1071 Certified
- UPC (low lead) certified
Warranty
- 1 year limited
- 10-Year warranty on thermostat
